Main Processor

Hi3518E

Sensor

1/2.8 COMS F23

Video

1920*1080@25fps

H.264 Bitrate self-adaptive

Suitable for changeable network environments(3G,4G or WIFI)

Audio

Two-way voice & Support echo cancellation

Built-in speaker

Built-in Microphone

View Angle

166 degree Horizontal

Day & Night

IR-CUT double filter automatically switches

6pcs infrared LED 850mm

Min Illumination:1 Lux

Connection

Support WiFi 2.4 GHz, IEEE 802.11 bgn

AP Hot spot

Scan QR code

Storage

Support SD card 8G / 16G / 32G/64G

Recording

Support smart phone local record, records video playback

Optional recording time setting between 15s-45s, once doorbell triggered

Screen Shot

Support Smart phone screen shots

Working Condition

Press Button Directly

PIR detection triggered

Mobile phone Control

Running up

System running up in millisecond

Inform

Push message within 1s-2s

Motion Detection

PIR motion detection, sensitivity High(2s)/ Medium(within 5s)/ Low (within 10 s)

Scene Mode

Backlight compensation

Infrared night vision

Quick movement

HLC

D-WDR

Share

Support QR code share(one-click generates QR-code, share to others

To add your doorbell devices, join in remote control. Maximum supports 7 authenticated users, supports users 3 view at the same time

Battery

3.7V, 2pcs 18650 battery, 3350mAH, Rechargeable or (8V~24V AC charging)

Power Consumption

Working 170mA, Standby 160μA
